Miniscat

Brief description

Miniscat is a compact atom scattering beamline designed to be compartible with the He-3 SpinEcho to perform preliminary measurements as well as independent atom diffraction experiments. The experiment is performed under high and ultra-high vacuum and involves scattering a beam of He-4 atoms off the sample. A custom sample transfer (compatible with the SpinEcho) is used for mounting samples within the scattering chamber and gaseous, liquid, and metallic species may be dosed in the scattering chamber. The apperatus has largely been built in house and therefore has a number of bespoke components.

Technical specifications

Item

Specification

Sample temperature range

20K – 1100K

Sample chamber vacuum range

1e-10mbar – 1e-7 mbar

Incident beam energy

8meV-65meV

Beam spot size

~3mm diameter

Compatibility

The substrate must be a single crystal of at least 5mm dimension. Dosing of gaseous, liquid, and metallic species is possible (please contact if you have a specific requirement). In general substrates should be able to withstand temperatures >100C. The sample mounting/sample transfer is not compatible with other techniques, therefore the substrate must be mounted in atmosphere on the custom sample cartridge.

Usage restrictions

Experiments are unlikely to be completed in less that 1wk of beam time.

Important information

The primary use of Miniscat is to support experiments performed on the He-3 SpinEcho. Often if new substrates/samples are used then a preliminary atom scattering study will be performed prior to the principle experiments on the SpinEcho, these measurements may take 1-2wk depending on the complexity of the substrate and any dosing/growth processes being studied. Miniscat provides a cheaper and less in demand beamline for these preliminary studies. In addition studies of helium diffraction, thermal desorption and uptake may be performed straightforwardly on a simple compact machine. Usual operation of the apparatus involves a researcher coming in person for the length of the experiments to perform the experiments with the support of an instrument scientist, technicians and local users. For theorists or groups that cannot send researches to the facility we offer a “full service” package where an expert in the field can help design and run your experiments.

Operating Status

in preparation

Booking

Whether you are new to the National Facility or have visited us before, our Getting Access page contains more information about booking our services.

Availability and lead times

Please allow two weeks between booking and use. Special requirements of the user may take longer time.

Pricing

For pricing details and more information about the services we can provide please contact us.
